HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型
更新：2015/6/25 17:05:23 點擊：
- 產品品牌 歐司朗OSRAM
- 產品型號 HQI-E/P
- 產品描述
HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型...
產品介紹
OSRAM HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型
OSRAM HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型產品特性
效率高，簡單的燈安裝/更換在開放式燈具，優異的顯色性，UV值明顯低于最大允許閾值的IEC 61167由于紫外線過濾器
OSRAM HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型應用領域
商場，會議室，禮堂，圖書館，工廠和車間，展覽廳、展銷會，火車站，地上和地下，步行區，廣場，適用于開放式和封閉式燈具，只有在合適的燈具室外應用
OSRAM HQI-E/P 400W/D OSRAM 金鹵燈泡稀土型產品特點
宏達石英技術，燈光顏色：暖白（WDL），中性白（NDL），日光（D），平均壽命：12000小時，平均壽命：9000小時（hqi-e / P 250 W／D），平均壽命：16000小時（hqi-e / P 400 W / D）
Electrical data
| Nominal wattage | 400 W |
|---|---|
| Rated wattage | 420.00 W |
| Lamp current | 4.00000 A |
| PFC capacitor at 50 Hz | 45 μF |
| Nominal voltage | 110 V |
| Ignition voltage | 4.0 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 76 lm/W |
| Rated luminous flux | 28000 lm |
Photometrical data
| Color rendering index Ra | 90 |
|---|---|
| Color temperature | 5100 K |
| Light color | 960 |
| Rated LLMF at 2,000 h | 0.83 |
| Rated LLMF at 4,000 h | 0.76 |
| Rated LLMF at 6,000 h | 0.70 |
| Rated LLMF at 8,000 h | 0.65 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 122.0 mm |
|---|---|
| Length | 290.0 mm |
| Product weight | 235.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 400 °C |
|---|---|
| Maximum permitted base edge temperature | 250 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.99 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.98 |
| Rated lamp survival factor at 6,000 h | 0.95 |
| Rated lamp survival factor at 8,000 h | 0.90 |
| Lifespan B50 | 16000 h |
Additional product data
| Product remark | With NAV control gear |
|---|---|
| Base (standard designation) | E40 |
| Design / version | Coated |
| Lamp mercury content | 59.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | Any |
| Enclosed luminaire required | No |
Certificates & standards
| Energy efficiency class | A |
|---|---|
| Energy consumption | 462 kWh/1000h |
