OSRAM HQI-TS 2000W/N/L（進口）雙端金鹵燈
更新：2015/6/24 13:40:45 點擊：
- 產品品牌
- 產品型號 HQI-TS 2000W/N/L
- 產品描述
歐司朗 HQI-TS 2000W/N/L（進口）雙端金鹵燈 國際光源照明專家--惠州同為照明有限公司 是國內最具規模的進口特種光源供應商之一，常年提供 原裝OSRAM（歐司朗）及其它著...
產品介紹
OSRAM HQI-TS 2000W/N/L（進口）雙端金鹵燈
OSRAM HQI-TS 2000W/N/L（進口）雙端金鹵燈產品的好處
非常高的效率，很高的光通量，壽命長，可使用常規點火器和控制裝置，理想的緊湊型泛光燈，良好的定位，由于k12s基地
OSRAM HQI-TS 2000W/N/L（進口）雙端金鹵燈應用領域
體育場館照明系統，工業設施，機場，碼頭和港口設施，編組站，集裝箱轉運設施，批準用于封閉式燈具，只有在合適的燈具室外應用
OSRAM HQI-TS 2000W/N/L（進口）雙端金鹵燈產品特點
宏達石英技術
Electrical data
| Nominal wattage | 2000 W |
|---|---|
| Rated wattage | 2150.00 W |
| Lamp current | 10.40000 A |
| PFC capacitor at 50 Hz | 60 μF |
| Nominal voltage | 200 V |
| Ignition voltage | 4.0 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 107 lm/W |
| Rated luminous flux | 230000 lm |
Photometrical data
| Color rendering index Ra | 65 |
|---|---|
| Color temperature | 4100 K |
| Light color | 642 |
| Rated LLMF at 2,000 h | 0.91 |
| Rated LLMF at 4,000 h | 0.85 |
| Rated LLMF at 6,000 h | 0.82 |
| Rated LLMF at 8,000 h | 0.80 |
| UV protection | No |
Light technical data
| Starting time | 120 s |
|---|
Dimensions & weight
| Diameter | 40.0 mm |
|---|---|
| Length | 274.0 mm |
| Light center length (LCL) | 137.0 mm |
| Product weight | 88.70 g |
Temperatures
| Maximum permitted outer bulb temperature | 950 °C |
|---|---|
| Maximum permitted pinch temperature | 390 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.95 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.83 |
| Rated lamp survival factor at 6,000 h | 0.67 |
| Rated lamp survival factor at 8,000 h | 0.50 |
| Lifespan B50 | 8000 h |
Additional product data
| Base (standard designation) | K12s-36 |
|---|---|
| Design / version | Clear |
| Lamp mercury content | 220.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | p15 |
| Enclosed luminaire required | Yes |
| Hot restart | Yes |
Certificates & standards
| Energy efficiency class | A+ |
|---|---|
| Energy consumption | 2365 kWh/1000h |
