OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL
更新：2015/6/24 11:57:21 點擊：
- 產品品牌 歐司朗OSRAM
- 產品型號 HQI-TS
- 產品描述
OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL...
產品介紹
OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL
OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL產品的好處
效率高，光線分布均勻，優異的顯色性，壽命長，熱重燃的能力，UV值明顯低于最大允許閾值的IEC 61167由于紫外線過濾器
OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL應用領域
大廳，接待區，工廠和低成本設備大廳照明，展覽廳、展銷會，體育廳和多功能廳，步行區，廣場，公園和花園，建筑物，紀念碑，橋，批準用于封閉式燈具，只有在合適的燈具室外應用
OSRAM HQI-TS 400W金鹵燈雙端NDL/WDL產品特點
宏達石英技術，燈光顏色：暖白（WDL），中性白（NDL），日光（D）
OSRAM HQI-TS 400 W/D 金鹵燈雙端
Electrical data
| Nominal wattage | 400 W |
|---|---|
| Rated wattage | 400.00 W |
| Lamp current | 4.00000 A |
| PFC capacitor at 50 Hz | 45 μF |
| Nominal voltage | 118 V |
| Ignition voltage | 4.0 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 83 lm/W |
| Rated luminous flux | 35000 lm |
Photometrical data
| Color rendering index Ra | 93 |
|---|---|
| Color temperature | 5500 K |
| Light color | 960 |
| Rated LLMF at 2,000 h | 0.70 |
| Rated LLMF at 4,000 h | 0.60 |
| Rated LLMF at 6,000 h | 0.55 |
| Rated LLMF at 8,000 h | 0.52 |
| Rated LLMF at 12,000 h | 0.50 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 33.0 mm |
|---|---|
| Length | 206.0 mm |
| Light center length (LCL) | 103.0 mm |
| Product weight | 92.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 650 °C |
|---|---|
| Maximum permitted pinch temperature | 300 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.95 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.90 |
| Rated lamp survival factor at 6,000 h | 0.85 |
| Rated lamp survival factor at 8,000 h | 0.80 |
| Rated lamp survival factor at 12,000 h | 0.50 |
| Lifespan B50 | 12000 h |
Additional product data
| Product remark | With NAV control gear |
|---|---|
| Base (standard designation) | Fc2 |
| Design / version | Clear |
| Lamp mercury content | 35.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | p45 |
| Enclosed luminaire required | Yes |
| Hot restart | Yes |
Certificates & standards
| Energy efficiency class | A |
|---|---|
| Energy consumption | 462 kWh/1000h |
