歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈
更新：2015/6/24 14:00:30 點擊：
- 產品品牌 歐司朗 OSRAM
- 產品型號 HQI-T 150W/WDL
- 產品描述
德國歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈...
產品介紹
歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈 德國產
歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈產品的好處
效率高，優異的顯色性，UV值明顯低于最大允許閾值的IEC 61167由于紫外線過濾器
歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈應用領域
商場，展覽廳、展銷會，工廠和車間，步行區，廣場，建筑物，紀念碑，橋，批準用于封閉式燈具，只有在合適的燈具室外應用
歐司朗 OSRAM HQI-T 150W/WDL 陶瓷金鹵燈產品特點
宏達石英技術，燈光顏色：暖白（WDL），中性白（NDL），平均壽命：9000小時
Electrical data
| Nominal wattage | 150 W |
|---|---|
| Rated wattage | 150.00 W |
| Lamp current | 1.80000 A |
| PFC capacitor at 50 Hz | 20 μF |
| Nominal voltage | 100 V |
| Ignition voltage | 3.6 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 87 lm/W |
| Rated luminous flux | 13000 lm |
Photometrical data
| Color rendering index Ra | 77 |
|---|---|
| Color temperature | 3000 K |
| Light color | 730 |
| Rated LLMF at 2,000 h | 0.80 |
| Rated LLMF at 4,000 h | 0.73 |
| Rated LLMF at 6,000 h | 0.69 |
| Rated LLMF at 8,000 h | 0.60 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 25.0 mm |
|---|---|
| Length | 84.0 mm |
| Light center length (LCL) | 56.0 mm |
| Product weight | 30.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 550 °C |
|---|
Lifespan
| Rated lamp survival factor at 2,000 h | 0.92 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.90 |
| Rated lamp survival factor at 6,000 h | 0.80 |
| Rated lamp survival factor at 8,000 h | 0.55 |
| Lifespan B50 | 9000 h |
Additional product data
| Base (standard designation) | G12 |
|---|---|
| Design / version | Clear |
| Lamp mercury content | 32.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | Any |
| Enclosed luminaire required | Yes |
Certificates & standards
| Energy efficiency class | A+ |
|---|---|
| Energy consumption | 165 kWh/1000h |
