OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈
更新：2015/6/24 13:43:10 點擊：
- 產品品牌
- 產品型號 OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈
- 產品描述
OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈 國際光源照明專家--惠州同為照明有限公司是 國內最具規模的進口特種光源供應商之一，常年提供 ...
產品介紹
OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈
OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈產品的好處
效率高，優異的顯色性，卓越的色彩穩定性，在燈泡的壽命光通量損失小，熱重燃的能力，小射燈，緊湊的尺寸，良好的定位，由于k12s基地
OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈應用領域
體育場館照明系統，體育廳和多功能廳，機場，太陽模擬，材料試驗，批準用于封閉式燈具，只有在合適的燈具室外應用
OSRAM HQI-TS 1000W/NDL/S 1000W/D/S（進口）雙端金鹵燈產品特點
宏達石英技術，燈光顏色：中性白（NDL），日光（D）
Electrical data
| Nominal wattage | 1000 W |
|---|---|
| Rated wattage | 1000.00 W |
| Lamp current | 9.70000 A |
| PFC capacitor at 50 Hz | 85 μF |
| Nominal voltage | 120 V |
| Ignition voltage | 4.0 / 5.0 kVp |
| Rated lamp efficacy (standard condition) | 90 lm/W |
| Rated luminous flux | 90000 lm |
Photometrical data
| Color rendering index Ra | 85 |
|---|---|
| Color temperature | 4400 K |
| Light color | 842 |
| Rated LLMF at 2,000 h | 0.91 |
| Rated LLMF at 4,000 h | 0.86 |
| Rated LLMF at 6,000 h | 0.84 |
| UV protection | No |
Dimensions & weight
| Diameter | 36.0 mm |
|---|---|
| Length | 187.0 mm |
| Light center length (LCL) | 93.0 mm |
| Product weight | 61.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 950 °C |
|---|---|
| Maximum permitted pinch temperature | 390 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.95 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.70 |
| Rated lamp survival factor at 6,000 h | 0.50 |
| Lifespan B50 | 6000 h |
Additional product data
| Base (standard designation) | K12s-36 |
|---|---|
| Design / version | Clear |
| Lamp mercury content | 70.0 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | p15 |
| Enclosed luminaire required | Yes |
| Hot restart | Yes |
Certificates & standards
| Energy efficiency class | A+ |
|---|---|
| Energy consumption | 1100 kWh/1000h |
