OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈
更新：2015/6/24 10:35:16 點擊：
- 產品品牌 OSRAM
- 產品型號 HCI-TF 20W/830, 35W/830
- 產品描述
OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈歐司朗照明廣東惠州同為有限公司 專業代理 德國OSRAM(歐司朗)光源、電器。PHILIPS（飛利浦）光源，電器、等名...
產品介紹
OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈
OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈產品優勢
效率高，優異的顯色性，很好的顏色穩定性，易relamping之前感謝扭鎖基地，UV值明顯低于最大允許閾值的IEC 61167由于紫外線過濾器
OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈應用領域
店內，商店的櫥窗，商場，大廳，接待區，博物館，展覽，重點照明，裝飾照明，批準用于封閉式燈具，只有在合適的燈具室外應用
OSRAM HCI-TF 20W/830, 35W/830（進口）陶瓷金鹵燈產品特點
強力球陶瓷技術，燈光顏色：暖白（830為930，WDL），平均壽命：15000小時，只有與心電圖70……運行400赫茲的方波電流，扭鎖基地
OSRAM HCI-TF 20 W/830 WDL （進口）陶瓷金鹵燈
Electrical data
| Nominal wattage | 20.0 W |
|---|---|
| Rated wattage | 20.00 W |
| Lamp current | 0.22 A |
| Ignition voltage | 3.0 / 5.0 kVp |
Photometrical data
| Luminous flux | 1700 lm |
|---|---|
| Luminous efficacy | 85 lm/W |
| Color rendering index Ra | 89 |
| Color temperature | 3000 K |
| Light color | 830 |
| Rated LLMF at 2,000 h | 0.80 |
| Rated LLMF at 4,000 h | 0.75 |
| Rated LLMF at 6,000 h | 0.73 |
| Rated LLMF at 8,000 h | 0.70 |
| Rated LLMF at 12,000 h | 0.69 |
| UV protection | Yes |
Dimensions & weight
| Diameter | 13.0 mm |
|---|---|
| Length | 57.0 mm |
| Light center length (LCL) | 30.0 mm |
| Product weight | 8.00 g |
Temperatures
| Maximum permitted outer bulb temperature | 380 °C |
|---|---|
| Maximum permitted pinch temperature | 330 °C |
Lifespan
| Rated lamp survival factor at 2,000 h | 0.99 |
|---|---|
| Rated lamp survival factor at 4,000 h | 0.98 |
| Rated lamp survival factor at 6,000 h | 0.97 |
| Rated lamp survival factor at 8,000 h | 0.96 |
| Rated lamp survival factor at 12,000 h | 0.80 |
| Lifespan B50 | 15000 h |
| Operation mode LLMF/LSF | ECG |
Additional product data
| Product remark | Only for operation with electronic control gear with 70…400 Hz square-wave current |
|---|---|
| Base (standard designation) | GU6.5 |
| System guarantee level | 3 (2/5) |
| Lamp mercury content | 3.5 mg |
Capabilities
| Dimmable | No |
|---|---|
| Burning position | Any |
| Enclosed luminaire required | Yes |
Certificates & standards
| Energy efficiency class | A |
|---|---|
| Energy consumption | 22 kWh/1000h |
